Apply angle relationships formed by intersecting lines

An intersection of two lines creates four angles: vertical angles are congruent, while adjacent angles form a linear pair and sum to 180°; perpendicular lines produce four right angles. The understanding includes interpreting marked diagrams, determining unknown angle measures, and representing relationships with simple equations while distinguishing equality from supplementary relationships. This scope is limited to a single intersection, not more advanced angle theorems involving transversals, polygons, or formal proofs.

Detailed Explanation: Apply angle relationships formed by intersecting lines

When two lines intersect, they form four angles.

Vertical angles are opposite each other, so they are equal:

m\angle 1=m\angle 3

Adjacent angles share a side. If their other sides form a straight line, they make a linear pair and add to $180^\circ$ :

m\angle 1+m\angle 2=180^\circ

Example

Two lines intersect. The upper-left angle measures $2x+20^\circ$ , and the upper-right angle measures $4x+10^\circ$ .

These two angles are adjacent and form a linear pair, so their measures add to $180^\circ$ :

(2x+20)+(4x+10)=180

Combine like terms:

6x+30=180

Subtract $30$ from both sides:

6x=150

Divide by $6$ :

x=25

Now substitute $25$ into each angle expression:

Upper-left angle:

2(25)+20=70^\circ

Upper-right angle:

4(25)+10=110^\circ

The angle opposite the $70^\circ$ angle is a vertical angle, so it also measures $70^\circ$ . The angle opposite the $110^\circ$ angle also measures $110^\circ$ .

So the four angles are:

70^\circ,\ 110^\circ,\ 70^\circ,\ 110^\circ

Remember: use equal when angles are vertical, and use sum to $180^\circ$ when adjacent angles form a linear pair.
