Dilate figures from the origin

A dilation centered at the origin maps each point $(x,y)$ to $(kx,ky)$ , where the scale factor $k$ may be an integer, fraction, or decimal; thus each coordinate and every distance from the origin is multiplied by $k$ . The image preserves angle measures and figure shape while changing size, supporting understanding of similarity and proportional relationships; this scope is limited to coordinate dilations centered at the origin, not arbitrary centers or more advanced transformations.

Detailed Explanation: Dilate figures from the origin

A dilation centered at the origin changes each point $(x,y)$ to

(x,y)\longrightarrow (kx,ky),

where $k$ is the scale factor. Multiply both coordinates by $k$ .

If $k>1$ , the figure becomes larger.
If $0<k<1$ , the figure becomes smaller.
Each image point stays on the same line from the origin as its original point.

Example

Dilate triangle $ABC$ by a scale factor of $2$ , where

A(-3,1),\qquad B(1,2),\qquad C(0,-2).

Step 1: Write the rule.

Since $k=2$ ,

(x,y)\longrightarrow (2x,2y).

Step 2: Dilate each vertex.

For point $A(-3,1)$ :

A'=(2(-3),2(1))=(-6,2).

For point $B(1,2)$ :

B'=(2(1),2(2))=(2,4).

For point $C(0,-2)$ :

C'=(2(0),2(-2))=(0,-4).

Step 3: State the image.

The dilated triangle has vertices

\boxed{A'(-6,2),\quad B'(2,4),\quad C'(0,-4)}.

To graph the image, plot these new points and connect them in the same order. The triangle has the same shape, but every distance from the origin is twice as large.
